Turbostage Schema reference

Background

Turbostage Schema is inspired by best-practice object-relational mapper systems by Apache and Microsoft.

It is a system which may spread across several databases and servers. Instead of using more schema layers to define the systems TurboStage defines the complete system in one layer.

Complex business logic is contained in code hooked up to the schema using the <execute> element, the code is however referenced in the schema making the schema covering all aspects – in one layer.

Definitions

Schema merging

Basis

The schema files define the data architecture and functionality. The only file that in fact is loaded by TurboStage is custom.schema.xml located in the tweak folder.

This root schema file may include other schema files.

All schema files must start with the <schema> tag. The following sample shows custom <schema> element. The schemasyntaxversion attribute may not be altered manually, it is reserved for public use by TurboStage to keep track of schema version and schema upgrade.

xxxxxxxxxx
<schema schemasyntaxversion="0.7">

You may design your own system from scratch, however some required types has to be defined in order for TurboStage to startup.

These minimum requirements are defined in /ts/schema/minimum.schema.xml which you may include and build your system from.

xxxxxxxxxx
<include src="/ts/schema/minimum.schema.xml" />

Include files

The normal procedure for using TurboStage as a business system covering portal and PDM functionality is to just include the Highstage schema file which defines types like Action, Document and Part.

For schema backward compatibility with old Highstage generation use:

xxxxxxxxxx
  <include src="/schema/highstage/highstage.schema.xml" />

Schema files are merged together in the order they are included. If a schema file file1 includes file2 then file2 is loaded first and then file1 is merged to produce the resulting schema xml.

Element merging

Merging of two schema files will be done by adding all elements to the resulting schema. However if two elements exists with the same element name then the elements will be merged.

Sample

xxxxxxxxxx
<!--Schema file 1:-->
    <element name=”x” />
<!--Schema file 2:-->
    <element name=”y” attribute=”a” />
<!--Schema file 3:-->
    <element name=”x” attribute=”b” />
<!--Resulting schema:-->
    <element name=”x” attribute=”b” />
    <element name=”y” attribute=”a” />

Note that it is important that all elements must be given names . If elements with no names exist, then an exception will occur at system reset.

Merge attributes

For all elements, the following XML merge attributes are available:

Semicolon separated attribute value list

Standard behavior is that when two elements are merged the attributes from the second element in overwrite the attribute values of the first element. However if the second elements attribute starts with "+=" then the attribute value will be concatenated to the first elements attribute value.

Sample:

xxxxxxxxxx
<!--Merge element 1:-->
     <element name=”x” attribute="a"/>
<!--Merge element 2:-->
     <element name=”x” attribute=”b” />
<!--Merge element 3:-->
     <element name=”x” attribute=”+=c;d” />
<!--Resulting element:-->
    <element name=”x” attribute=”b;c;d” />

Inheritance

Inheritance is resolved by first merging leaf's and then merging each level until the root is reached. If one type inherits from several other types then merging is done from left to right.

Merge variables

Merge variables @@[<variable-name>] may be used in schema xml files that are included by other schema xml files. The <include> element documented later in this document will replace merge variables with attributes in the <include> element. Merge variables that do not have a corresponding <include> element attribute with identical name will result in schema load exception.

Runtime variables

Runtime variables @[<variable-name>] may be used various places in schema xml, refer to element documentation later in this document.

<schema> element

Starting with the <schema> element the following attributes and elements are available:

Attributes:

Elements:

<execute> element

This element specifies a page to execute after the schema has been loaded. This allows for performing specific custom code at startup or setting delegates to custom code.

Attributes:

Sample loading folder feature:

xxxxxxxxxx
<execute name="builtin" src="~/ts/feature/folder.aspx" />

<css> element

Includes html cascading style sheet (CSS).

Attributes:

Sample:

xxxxxxxxxx
<css name"style" src"/tweak/style.css" />

<include> element

The include element loads additional schema xml files.

Attributes:

Samples on src attribute:

Path relative to the folder containing the current schema file:

xxxxxxxxxx
<include src="sample.schema.xml" />

Absolute path:

xxxxxxxxxx
<include src="c:\...\sample.schema.xml" />
<include src="\\server\share\...\sample.schema.xml" />

Path relative to web application root folder:

xxxxxxxxxx
<include src="/tweak/sample.schema.xml" />
<include src="\tweak\sample.schema.xml" />

Samples on <parameters>:

All attributes of the include element may be used as parameters in the include file:

xxxxxxxxxx
<include src="/schema/axapta.schema.xml" typePrefix="AXAPTA:" tablePrefix="AXAPTA.dbo." sqlmanage="0" dataareaid="DAT"/>

The value of attribute typePrefix will replace all occurrences of @@[typePrefix].

Samples on <_remove>:

Include schema imported from HS, but we are mainly interested en column definitions and want to remove all menu, main and form nodes:

xxxxxxxxxx
  <include src="HS_Imported.schema.xml" _remove="//main;//menu;//form" />

<job> element

The job runs specific web pages at a specific interval or time.

Attributes:

The interval and time attributes may be combined but normally just one of them are used.

Sample:

The following sample runs the local server page replicate.aspx at 1 hour interval:

xxxxxxxxxx
  <job name="LdapReplicate0100I" interval="01:00" url="/ts/ldap/replicate.aspx" />

<js> element

Includes JavaScrips file and/or inline JavaScript.

Attributes:

Sample:

xxxxxxxxxx
<js name="jquerytextareaautosize" src="ts/jquery/plugin/jquery.autosize-min.js">
    <![CDATA[ $(function () { $('textarea').autosize(); }); ]]>
 </js>

<type> element

The type element defines a specific object type. Refer to Schema_type_element.htm for more information on the <type> element.

Advanced process security

Refer to TN10682-1.pdf

Integrating foreign systems

Foreign systems are integrated by creating a schema for the system or the parts of the system that are relevant for integration. As an example ERP systems typically contains many tables (up to many thousands) of which only a few tables (~10) are relevant for the daily core business.

If the foreign system tables are not contained on the same SQL server as TurboStage then the SQL server must be linked to the TurboStage SQL server and the foreign system tables must be referenced using a fully qualified path where <server> is the name of the linked server:

xxxxxxxxxx
<server>.<database name>.<schema name>.<table name>

Sample of a fully qualified path:

xxxxxxxxxx
sql1.axapta.dbo.custtable

IMPORTANT The foreign system types should typically have sqlmanage attribute set to ‘0’ to eliminate risk of redefining foreign SQL tables. The user name used for linked server login should typically have read-only access.
